XY3100E
XY3100E is a high-performance, highly integrated SoC chip designed for NB-IoT, BLE,and GNSS scenarios.
This chip is fully compatible with the 3GPP R13/R14 protocols and the lowpower Bluetooth 5.1 protocol, offering a low-power, cost-effective solution for IoT applications, such as smart city, intelligent transportation, asset tracking, logistics tracking, remote healthcare etc.
Product Advantage
-
-
NB-IoT highly integrated
Integrated PA, filter, Switch, etc.
-
NB-IoT ultra-low power and ultra-high performance
DeepSleep:2.5uA;TX 250mA@23dB; RX 20mA
support ultra-wide voltage : 2.2-4.5V
sensitivity : simplix communication -118dBm
-
GNSS ultra-low power and ultra-high performance
GNSS acquisition power consumption: 42mW
GNSS tracking power consumption: 39mW
GNSS backup power consumption: 5uA
Cold start sensitivity -148dBm
Hot start sensitivity -155dBm
Re-capture sensitivity -156dBm
Sensitivity tracking -161dBm
-
BLE ultra-low power and ultra-high performance
TX power 0dBm(typical), 8dBm(Max)
RX -96dBm @ BLE 1Mbps -94dBm @ BLE 2Mbps
30mA BLE TX@0dBm@1Mbps
22mA BLE RX@0dBm@1Mbps
-
Basic Parameter
-
-
Communication protocol
R13, R14, R15
-
Processor
ARM Cortex - M3; 32K~92Mhz
-
Encapsulation
7mm*8.5mm QFN78
-
Frequency band
Bands 1/3/4/5/8/12/20/28/71
-
Hardware peripheral
UART/CSP/GPIO /ADC/I2C/SPI/ QSPI etc.
-
Operating temperature
-40°C to +85°C
-
